Jultec JAD309TSM

The Jultec JAD309TSM is a high-performance end antenna socket designed for modern satellite and broadband installations utilizing the Unicable (EN50494) and JESS (Jultec Enhanced Stacking System) standards. This socket is ideal for setups where multiple receivers share a single cable, providing efficient signal distribution and reliable performance.

Key Features

• End Antenna Socket: Specifically designed to terminate a trunk line in satellite and broadband installations.

• Diodenentkoppelt (Diode Decoupled): Ensures isolation between the trunk and branch lines, preventing interference and signal degradation.

• Frequency Range:

  • Trunk Line: 15 MHz to 2,150 MHz

  • TV Branch: 258 MHz to 862 MHz

  • Satellite Branch: 1,350 MHz to 2,150 MHz

  • Modem Branch: 15 MHz to 1,218 MHz

• Attenuation:

  • TV Branch: -9 dB

  • Satellite Branch: -9 dB

  • Modem Branch: -9 dB

• Maximum Modem Signal Level: 120 dBµV (with Intermodulation Distortion less than 5 dBµV)

• DC Pass: Supports up to 500 mA, facilitating power supply through the trunk line.

• EMC Shielding: Complies with CE Class A standards, ensuring minimal electromagnetic interference.

• Installation Depth: 20.5 mm, suitable for standard wall boxes.

 Compatibility

The JAD309TSM is compatible with Unicable and JESS systems, allowing multiple receivers to operate over a single cable. It is designed to work with Jultec's range of Unicable converters and multiswitches, ensuring seamless integration and optimal performance.

 Applications

• Residential Installations: Ideal for homes with multiple satellite receivers, providing a tidy and efficient cabling solution.

• Commercial Settings: Suitable for hotels, apartments, and other multi-dwelling units requiring reliable satellite and broadband distribution.

• Broadband Networks: Supports DOCSIS 3.1 and 4.0 standards, making it compatible with modern broadband infrastructures

The JAD309TSM is designed for use with Unicable and JESS systems. It should not be used in traditional multi-switch setups with legacy signals due to overlapping frequency ranges. For installations spanning multiple dwellings, Jultec's programmable JAP series sockets are recommended to ensure proper signal management and prevent interference.
